ICON - LP 200 Pressure Transmitter

The ICON LP200 Pressure Transmitter was designed to measure Pressure or Level within industry’s most demanding corrosive process applications. When measuring pressure It can be mounted vertically or horizontally, and can easily be installed into a threade.

Call 800-370-0439 for pricing
Part Number
  • 999-1566-001
Manufactured
Availability
  • Call for availability

Features

  • PP | PVDF | 316 SST Body
  • Optional LED Display
  • Pressure Range | 0 – 225 psi
  • Output | 4-20mA | 2 Wire Loop Powered
  • NPT | G | Union Type Connection
  • Ceramic Sensing Diaphragm
  • No Programming Required
  • Applications
    • Chemicals | Acids | Bases
    • Tank Level
    • Industrial Process Piping
    • Vapor Pressure
    • Leak Detection Equipment
The iCON LP200 implements a state of the art ceramic measuring principle that changes the physical pressure which equates to no more than a few microns into a linear electronic signal that can be measured. This minimal deformation equates to negligible material strain of the ceramic electronic pressure-sensing diaphragm resulting in high resistance to alternating loads and long-term durability. Exactly what is required for tough industrial applications.
