SeaMetrics - Industrial Magmeter - EX100/200 Series Adjustable Mag Meter

The EX100/200-Series are adjustable depth insertion magmeters that fit 3” to 48” pipe (up to 72” optional). The complete lack of moving parts of the EX100/200-Series is the source of its reliability. Brass and stainless steel models withstand a variety of.

Call 800-370-0439 for pricing
Part Number
  • 999-637-004
Manufactured
Availability
  • Call for availability

Features

  • Depth adjustable sensors
  • EX110 fits any 1-1/2″ pipe fitting (standard saddle, for instance) and adjusts to pipe sizes 3-10″
  • EX210 adjusts to pipe sizes 10-48″
  • Meter extends only about 1/8 of pipe diameter, minimizing potential for clogging with debris
  • Accept Seametrics modules for rate and total indication, 4-20 mA conversion, data logging, and flow switching
  • Alternatively, signal can be sent directly to a PLC or other control
  • Available in brass or 316 stainless steel
  • Immersibility and reverse flow output available
  • Applications
    • 3"-48" pump (up to 72" optional)
    • Clean or "Dirty" liquids
    • Conductive liquids
    • Municipal
    • Industrial
    • Irrigation
The EX100/200-Series are adjustable depth insertion magmeters that fit 3" to 48" pipe (up to 72" optional). The complete lack of moving parts of the EX100/200-Series is the source of its reliability. Brass and stainless steel models withstand a variety of temperature, pressure, and chemical conditions. The EX-Series has no rotor to stop turning in dirty water and there are no bearings to wear out. Like all magmeters, when used in chemical injection applications, these meters should be installed upstream of the chemical line (or far enough downstream to allow complete mixing of fluids before the meter). Adapters mate with standard 1-1/2" (11x/21x) or 2" (15x/25x) FNPT threaded fittings such as saddles and weldolets which may be purchased as well. NSF-61 Certified: The stainless steel versions of our popular EX Series Insertion Magmeters are now certified! Please note that this only applies to units purchased with standard EPDM o-rings, Viton o-rings are still pending certification.
